| Brand Name : | SMATIPC |
| Model Number : | IEXP-512 |
| Certification : | CE, ROHS,FCC,ISO9001 |
| Payment Terms : | T/T,Paypal |
| Delivery Time : | 5-8 work days |
A Book Type Industrial Computer That Is Designed To Resemble A Thin Book.
All-aluminum alloy structure, fanless cooling design
12th Gen Intel Alder Lake U Series Deca-Core Processor
2xDDR5 4800MHz SODIMM,max 64 GB
2xDP, synchronous/asynchronous dual display
3xIntel i210 lan + 1xIntel i219 lan (LAN1 support Vpro)
1xM.2 slot + 1xMSATA slot + 1xMini PCIE slot (support M.2 SSD +
MSATA SSD + WIFI/4G at the same time)
Specification
Parameter-IEXP-512 | |
Processor | Intel i5-1235U (10 core 12 threads, Turbo. 4.4 GHz) |
| Intel i7-1255U (10 core 12 threads,Turbo. 4.7 GHz) | |
Chipset | Alder Lake-U |
Memory | 2xDDR5 4800 , Max 64 GB |
Storage | 1x M.2 2280 M-key slot (support SATA SSD & NVME SSD PCEIE 1X ) |
| 1xMSATA | |
I/O Port | |
Display Port | 2xDP(Resolution 7680 x 4320 @60Hz) |
Lan Port | 3xIntel i210-AT, 1xIntel i219-LM 1000M Ethernet |
USB | 4xUSB 3.0 |
COM | Standard None, Optional 2xCOM (COM1/2 RS232/485) |
Power supply | 1x4Pin Phoenix terminal power supply,DC 12V~24V wide voltage input |
Drawing
Application
IEXP-512 book-type IPC is suitable for a variety of application scenarios, such as the following aspects:
Logistics & Warehouse Management: Book-type IPC can be used in logistics and warehouse management systems to control and monitor logistics equipment, warehouse automation systems, etc. They can realize functions such as order processing, inventory management, transportation tracking, etc., and improve logistics efficiency and management accuracy.
Industrial Automation: Book-type IPCs are widely used in the field
of industrial automation to control and monitor production lines,
mechanical equipment, process, etc. They can be used in conjunction
with sensors, actuators and other industrial control equipment to
achieve automatic control and data acquisition.
|
|
